MT 160 – Evolution Care

Motorized Long Term Care

The Evolution Care MT 160 bed is designed to meet the demands of comfort, safety, and functionality in hospital settings. It features a four-section articulated bed platform, allowing precise adjustments to the backrest, leg rest, and height—essential for patient care and recovery. The bed is equipped with an electric motorized elevation system, a carbon steel frame with anti-corrosion treatment, and 5-inch casters with diagonal brakes for easy movement and stability. It includes foldable siderails and a removable panel to facilitate access and cleaning, making it an efficient choice for hospitals and clinics. Registered Product:

Consult Anvisa

Adicionar o orçamento

SKU: 1677 Categories: Hospital Bed, Long-term Care, Recovery hospital bed

The Evolution Bed is a motorized hospital bed featuring a range of optional add-ons. Combined with its new graphic design, it offers exceptional value for money! Built with steel tubing and reinforced base structure, it includes an anti-corrosion chemical treatment and electrostatic painting, ensuring outstanding durability. The sleeping surface is articulated into four sections and equipped with removable ABS trays.

Download technical specifications

Standard Features:

CPR + One-Touch Bed Lowering to Minimum Position
Digital Controls on the Right Side, Internal and External
Motorized Height Adjustment
Electric Leg Rest
Siderails with Locking Mechanism
Single-Bandage Casters
Removable Bed Platform Fairing for Cleaning
Base Fairing
Removable Footboard and Headboard with Exclusive Easy-Fit System
Individual Brakes on All 4 Casters
5″ Casters
Bumpers
Bed Extension
Metal Structure with Electrostatic Coating
Backrest Angle Indicators
Trendelenburg and Reverse Trendelenburg Angle Indicators
Liquid Splash Protection: IPX4

Batería	ACO 79
Suporte para Oxigênio EVO	ACO 23
Movimento One Touch	ACO 85 One Touch Movement
Sistema Bluetooth	ACO 77 Sound in one Siderail
Controle remoto	ACO 60
Digital Evo	ACO 68, ACO 69, ACO 70, Right Side
Roda	ACO 05 4" Caster, ACO 06 – 6" Caster ans Individual Brake, ACO 07 – 6" Caster and Directional and Total Brake
Sensores	ACO 80 Brake, ACO 81 Partial Exit, ACO 82 Height, ACO 83 Lowered Siderail, No sensor
Balança	ACO 84
Quinta Roda	ACO 33
Raio X evolution	ACO 95
Suporte para soro	MT 935
Personalização	ACO 42 – Evolution Siderails, ACO 43 – Evolution Footboard and Headboard

Technical Specifications

MT – 160

The inpatient unit will never be the same again!

A feature designed with you in mind!

Customization of Siderails, Headboard, and Footboard
Add your logo, a phrase, or any personalization you want with this optional feature offered by Metahospitalar. To learn more, consult your representative or click here to speak directly with our online consultant.

Technical Specifications

Numero do Modelo MT-160
Carga de Trabalho (Indica a soma dos pesos do paciente, colchão e acessórios) 280 Kg
Peso máximo do paciente 250 Kg
Peso do produto 120 Kg

Tamanho Total da Cama
Comprimento ≈228 cm
Comprimento com extensor de leito ≈248 cm
Largura 109 cm

Altura sem Colchão
Máxima 68 cm
Mínima 33 cm

Movimentos

Dorso 0-77º

Pernas 0-23º

Elevação 330 mm - 680 mm

Trendelenburg -15º

Proclive 15º

Chair Position

Descriptive for Bidders

Download Discriptive for Bidders

EVOLUTION CARE MT-160
Present ANVISA Registration.
Structure:
Tubular structure with sheets of various thicknesses made of carbon steel, designed to withstand the product’s stress and nominal load capacity.
Chassis constructed with 50 x 30 x 2.0 mm tubes and 1/4″ thick sheets.
Platform composed of a 50 x 30 x 2.0 mm tube structure with 3/8” thick sheets.
The metal frame of the bed platform consists of four articulated sections made with a 30 x 20 x 1.2 mm tube structure and 3/16” thick sheets.
Optional Features:
Similar structure with the same characteristics in stainless steel.
Similar structure with the same characteristics in aluminum.
Bed platform constructed with “U”-shaped carbon steel profiles, 3.2 mm thick, available in carbon steel, stainless steel, or aluminum.
Bed Platform:
Structured thermoplastic platform with patient containment and mattress stopper.

The bed platform is independently secured to the four articulated sections of the metal frame, ensuring durability and stability. Optional:
Removable Structured Thermoplastic Bed Platform
Removable Perforated or Smooth Stainless Steel Bed Platform
Removable Perforated or Smooth Carbon Steel Bed Platform
Removable Perforated or Smooth Aluminum Bed Platform
Removable ABS Bed Platform
Bed Platform Made of Wooden Sheets (MDP, MDF, or TS)
Movement:
Vertical movement performed by a mechanical system in carbon steel, which transforms the horizontal linear motion of the motors into vertical motion of the bed, enabling height adjustment.

Bed movements are performed using four motors and an adjustable system with six positions. The bed’s movements include: Fowler, Semi-Fowler, backrest elevation, leg elevation, bed height adjustment (raising and lowering), Trendelenburg, Reverse Trendelenburg, chair position, vascular position, cardiac position, and auto-contour.
Optional Movement Systems:
Mechanical system with similar characteristics in stainless steel
Mechanical system with similar characteristics in aluminum
Retractable crank
Optional Motorization:
Two motors
Three motors
Five motors
Optional Movements:
CPR (Quick Release)
CPR + One-Touch Bed Lowering to Minimum Position
Cardiac Chair Position
One-Touch Chair Position
Electronic Controls:
Mobile hand control with locking mechanism
Options:
Mobile hand control without locking mechanism
Vertical control on the siderail
Horizontal control on the siderail
Supervisor with display on the siderail
Supervisor without display on the siderail
Supervisor with display on the footboard
Supervisor without display on the footboard
Supervisor control on the bed platform structure
Mobile satellite supervisor with cable
Mobile satellite supervisor with locking mechanism
Casters and Brake System:
6″ thermoplastic casters, offering floor protection, low noise during movement, and excellent load capacity.
Individual braking system on all four casters, activated via a pedal with stationary locking function for both rotation and translation.
Siderails and Siderail System:
Set of four classic enclosed siderails made from high-impact injected polyethylene.

Retractable system with locking mechanism. Optional Side Rails:
Six polyethylene side rails, flexible enclosed model
Four polyethylene side rails, flexible model with escape route
Four polyethylene side rails, new premium enclosed model
Four polyethylene side rails, new premium model with escape route
Two metal tube side rails (carbon steel, stainless steel, or aluminum) 3/4″ x 1.2mm or wood (MDF, MDP, or TS) with escape route
Four metal tube side rails (carbon steel, stainless steel, or aluminum) 3/4″ x 1.2mm or wood (MDF, MDP, or TS) enclosed
Two metal tube side rails (carbon steel, stainless steel, or aluminum) 3/4″ x 1.2mm or wood (MDF, MDP, or TS) enclosed
Optional Side Rail System:
Compact system with lock
Universal up/down system with lock
Stacking system
Headboard, Footboard, and Headboard Mounting:
Headboard and footboard in high-impact injected polyethylene, classic model.
Mounting with lock and removable.
Optional Headboard and Footboard:
High-impact injected polyethylene, flexible model
High-impact injected polyethylene, new premium model
Metal tube (carbon steel, stainless steel, or aluminum) 3/4″ x 1.2mm
Wood (MDF, MDP, or TS)
Optional Headboard Mounting:
Removable mounting without lock
Fixed mounting
Surface Finish of the Metal Structure:
All carbon steel structures undergo a chemical rust-resistant treatment and electrostatic powder coating, baked at 220°C (428°F) in an oven to increase the chemical resistance of the structure.
Optional:
High-gloss polishing for stainless steel, ensuring excellent asepsis
Chassis Finish:
Complete thermoplastic coating for chassis.
Optional:
No coating
Partial thermoplastic coating for chassis only on wheels
Partial or complete aluminum coating
Partial or complete painted carbon steel coating
Partial or complete stainless steel coating
Technical Data:
Fowler Backrest: 75° ~ 77° tilt
Fowler Legrest: 20° ~ 23° tilt
Trendelenburg: 0° ~ (-15°)
Reverse Trendelenburg: 0° ~ 15°
Maximum Elevation: 0.68 m (26.77 inches)
Minimum Elevation: 0.33 m (12.99 inches)
Bed: Length 19502150mm (76.7784.65 inches) x Width 830mm (32.68 inches) x Height 330680mm (12.9926.77 inches)
Total: Length 22802480mm (89.7697.64 inches) x Width 1090mm (42.91 inches) x Height 330680mm (12.9926.77 inches)
Maximum Working Load: 280 kg (617.29 lbs) / Maximum Patient Weight: 250 kg (551.16 lbs)
Optional:
Bed:Length: 17002280mm (66.9389.76 inches)
Width: 7001100mm (27.5643.31 inches)
Height: 300830mm (11.8132.68 inches)
Total:Length: 20002400mm (78.7494.49 inches)
Width: 10001500mm (39.3759.06 inches)
Height: 300830mm (11.8132.68 inches)
Maximum Working Load / Maximum Patient Weight:Maximum Working Load: 180 kg (396.83 lbs) / Maximum Patient Weight: 150 kg (330.69 lbs)
Maximum Working Load: 280 kg (617.29 lbs) / Maximum Patient Weight: 250 kg (551.16 lbs)
A sample may be requested at the hospital’s discretion.
